Sale of all types of flow control, Serjeki and Festo

Sale of all types of flow control, Serjeki and Festo

Serjeki flow controls have different types:

Flow controls that control the flow path or the entry of compressed air into the cylinder. Using these flow controls causes a drop in the input pressure to the cylinder and lower initial power of the cylinder during operation. The application of these products is concrete when we do not want the cylinder to operate with the nominal diameter and with all the force it can exert at the desired pressure. It is normal for this flow control model to drain the return flow path due to the presence of a one-way valve with high pressure and all the force of the cylinder. This flow control model has used the letter Z in its definition among Festo products. Throat adjustable flow controls that control both the inlet and outlet of compressed air. Like an adjustable dam, this flow control controls the entry and exit of compressed air equally. This flow control model among Festo products has used the letter O in its definition. Flow controls that control the return path or outflow of compressed air from the cylinder. This type of flow control is the most common flow control model in which the flow path is completely open and the air flow enters the cylinder with the maximum flow and causes the cylinder to move forward with maximum force. The work of this type of flow control is in the return direction, that is, when the cylinder is in the empty state. This flow control restricts the airflow path according to the user's manual setting so that the cylinder can return slowly and at the desired speed with maximum power. This flow control model among Festo products has used the letter A in its definition. Sale of types of flow control serjeki Festo in different sizes (M3-M5-1/8-1/4-1/2) Screw and screwdriver models Metal and plastic and hose feeding model (Kafni) (standard current rate) (type) 193152 GRLA-1/2-QS-12-D 1580 l/min 534344 GRLA-1/2-QS-12-RS-D 1580 l/min 193148 GRLA-1/4-QS-10-D 480 l/min 534340 GRLA-1/4-QS-10-RS-D 480 l/min 193146 GRLA-1/4-QS-6-D 400 l/min 534338 GRLA-1/4-QS-6-RS-D 400 l/min 193147 GRLA-1/4-QS-8-D 475 l/min 534339 GRLA-1/4-QS-8-RS-D 475 l/min 193142 GRLA-1/8-QS-3-D 130 l/min 197579 GRLA-1/8-QS-3-RS-D 130 l/min 193143 GRLA-1/8-QS-4-D 160 l/min 197580 GRLA-1/8-QS-4-RS-D 160 l/min 193144 GRLA-1/8-QS-6-D 185 l/min 537075 GRLA-1/8-QS-6-MF-D 400 l/min 197581 GRLA-1/8-QS-6-RS-D 185 l/min 193145 GRLA-1/8-QS-8-D 215 l/min 537076 GRLA-1/8-QS-8-MF-D 475 l/min 534337 GRLA-1/8-QS-8-RS-D 215 l/min 193151 GRLA-3/8-QS-10-D 900 l/min 534343 GRLA-3/8-QS-10-RS-D 900 l/min 193149 GRLA-3/8-QS-6-D 495 l/min 534341 GRLA-3/8-QS-6-RS-D 495 l/min 193150 GRLA-3/8-QS-8-D 820 l/min 534342 GRLA-3/8-QS-8-RS-D 820 l/min 193137 GRLA-M5-QS-3-D 100 l/min 197576 GRLA-M5-QS-3-RS-D 100 l/min 193138 GRLA-M5-QS-4-D 110 l/min 197577 GRLA-M5-QS-4-RS-D 110 l/min 193139 GRLA-M5-QS-6-D 115 l/min 197578 GRLA-M5-QS-6-RS-D 115 l/min 193156 GRLZ-1/8-QS-3-D 130 l/min 193157 GRLZ-1/8-QS-4-D 160 l/min 193158 GRLZ-1/8-QS-6-D 185 l/min 193159 GRLZ-1/8-QS-8-D 215 l/min 193153 GRLZ-M5-QS-3-D 100 l/min 193154 GRLZ-M5-QS-4-D 110 l/min 193155 GRLZ-M5-QS-6-D 115 l/min 161407 CRGRLA-1/2-B 2100 l/min 161405 CRGRLA-1/4-B 610 l/min 3720 GR-1/2 1620 l/min 2101 GR-1/4 370 l/min 151215 GR-1/8-B 210 l/min 152612 GR-1/8X2-B 190 l/min 2103 GR-3/4 3300 l/min 6308 GR-3/8-B 1010 l/min 6509 GRA-1/4-B 420 l/min 151213 GR-M5-B 115 l/min 193967 GR-QS-4 110 l/min 193969 GR-QS-6 230 l/min 193970 GR-QS-8 250 l/min
