Rail file rack

Rail file rack

Rail filing rack
Tandis company is a manufacturer of rail filing rack, mechanical rail rack, mobile rail filing system and rail filing cabinet to create a suitable space for filing documents such as Zonken, file box, folder and folders of medical documents.\r \n
Technical specifications of the rail filing rack
This system has shock-absorbing rubbers to prevent the units from colliding with each other and causing noise. It has.
The columns are made of st12 sheet.
The chassis is made of 40x80 mm profile with a thickness of 2 mm.
The panel and covers are made of 1 mm thick sheet.\r \nThe back covers are made of 1 mm thick sheet.
The filing system is equipped with a door and a central lock.
The straps are made of 7/5 grade wire and can also be adjusted with a strap.
The layers can be adjusted. Moving by bending one layer, each floor can bear 200 kg widely. The movement system is in the form of chain gear and gearbox gear. The type of st12 steel sheet is low alloy and high strength. nThe bearings are of zz type.
The steering wheel is made of two materials: Liberglass and polyethylene, which is flexible and non-fragile. r\nThe clamps of the classification system are made of 1.25 mm sheet.
The wheels are made of high-quality cast iron and machined in the form of a pulley.
The floor rails of the system are made of Trans 20.
The gears of chains and wheels The gear is made of plated steel.
The drive chain is a mechanical system of industrial type 40.
The painting after degreasing and phosphating is by electrostatic powder method and is baked at 220 degrees Celsius.\r \nProduction is possible with MDF covers and MDF doors.
The above rail system has a 5-year warranty and 12-year after-sales service from the final delivery date.
For more information, contact our experts. Get it.

With a 3-year warranty and 12 years of after-sales service

Shipping to all parts of the country
